Sokkia Set02N Total Station

Model

SET-02N

Telescope

Length

150mm

Objective??aperture

45mm(EDM:?50mm)

Magnification

30??¡Á


Erect

Field??of??view

1¡ã?30′

Resolving??power

3.0??”

Shortest??focus

1.3m

Distance??measurement??section

Single??prism

2,?000m

Three??prism

2700m

Measuring??Accuracy

¡À?(2mm+2ppm¡Á?D)m.?s.?e

Measuring??time

(first??time)

fine

1.2sec(4sec)

tracking

0.4sec(3sec)

Angle??measurement??section

Accuracy

2??”

Method

Absolute??encoder

Minimum??readout

1″?/5??”

Diameter??of??circle

71mm

displaying

display

Double??sides

Tilt??compensator

method

Single??axis

range

¡À?3′

Level??sensitivity

Circular??level

10′?/2mm

Plate??level

30??”?/2mm

Optical??plummet

Magnification

3x

Focus??range

0.5m-¡Þ

Field??of??view

5¡ã

Durability

Proof??water

and??dust

IP54

Working??temperature

-20

Power??supply

Charger

TBC-2

Battery

TBB-2,?2300mA

7.2V(NI-MH)

Working??time

45hours

(angle??measurement)

10hours

(angle??and??distance??measurement)

others

size

336H¡Á?184W¡Á?172L

Weight(with??battery)

4.9kg

Data??port

RS-232C

Internal??memory

24000points
