Rugged Bluetooth Mini RTK GNSS Receiver Support 4G Network
$2,050.00
Did you like this product? Add to favorites now and follow the product.
(+800) 1234 5678 90 Start Live Chat
Description
| Type: | GPS Receiver | GPS: | L1CA/L1P/L1C/L2P/L2C/L5 |
|---|---|---|---|
| GLONASS: | G1, G2, G3 | Galileol: | E1, E5a, E5b, ALTBOC, E6 |
| QZSS: | L1, L2 L5, | BeiDou: | B1I, B2I, B3I, B1C, B2a, B2b, ACEBOC |
| SBAS: | Ll, L5 | Wate Proof: | IP67 |
| Highlight: | Rugged RTK GNSS Receiver
, 4G RTK GNSS Receiver , Rugged Bluetooth RTK Receiver |
||
Mini rtk gps gnss receiver CHC E91 with rugged design 624 channel support 4G network bluetooth
RTK GNSS Receiver information
Internal 4G network modem
Embedded 4G modem for stable network
RTK connections. The E91 can also be set as?Wi-Fi hotspot for the controller to access the?Internet
Integrated UHF modem
E91 integrated UHF modem can be set at
frequencies between 410 MHz – 470 MHz with up
to5 km workingrange
Rugged design
The rugged and durable design meets the IP67
environmental standard for water and dust. The
E91 can survive a 2 m drop onto concrete
Packaging is absolutely fine, high-end and upscale. We have been dealing with foreign clients for more than 8 years. Before leaving the factory, every part is strictly tested.Please rest assured that we have all the necessary accessories for the instrument.
We have strong cooperation with DHL, TNT, UPS, FEDEX,EMS,China Air Post.
You can also choose your own shipping forwarder.
RTK GNSS Receiver information specification
|
Update rate
|
5 Hz, up to 50 Hz |
|
Performance Specifications |
|
|
Signal Reacquisition
|
< 1 sec
|
|
Hot Start
|
< 10 sec
|
|
Initialization Reliability
|
> 99.9%
|
|
Memory
|
8 GB
|
| Real-Time Accuracy (rms) | |
|
Static Accuracy
|
Horizontal:3mm + 1ppm
Vertical:5 mm + 1 ppm
|
|
RTK Accuracy
|
Horizontal:8 mm + 1 ppm
Vertical:15 mm + 1 ppm
|
|
Code Differential
|
Horizontal:0.4 m |
|
SBAS Accuracy
|
Horizontal:0.8 m |
|
Communication
|
|
|
7-pin
|
Connect to external power and radio
|
|
USB
|
For charging and data transmission
|
|
Cellular
|
Global 4G
|
|
Bluetooth
|
V4.1
|
|
WIFI
|
802.11 ac/n/b/g/n
|
|
WebUI
|
Update firmware, manage settings and
status, download data
|
|
Date formats
|
CNR input and out put
RTCM 2.x, RTCM 3.x input and output |
|
Electronic Bubble
|
Support
|
|
Dimensions
|
160*158*96mm , 1.55KG |
|
Shock
|
Survive a 2 m pole drop on concrete floor 1.2 m free drop
|
| 5-pin lemo port | connecting external power supply and external radio |
|
SIM Card
|
NANO SIM
|
|
Cellular
|
Global 4G
|
|
Bluetooth
|
V2.1+EDR / V4.1 Dual Mode, Class 2
|
|
WIFI
|
802.11 ac/n/b/g/n
|
|
WebUI
|
Update firmware, manage settings and
status, download data
|
|
Electronic Bubble
|
Support
|
|
Environment
|
|
|
Dustproof&Waterproof
|
IP67 (Customizable IP68)
|
|
Humidity
|
95% non-condense
|
|
Power Supply
|
|
|
Battery
|
Rechargeable, built-in Lithium-ion battery,7.2 V – 10200 mAh |
|
Voltage
|
9~28 V DC external power input
|
|
Working Time
|
Up to 16 hours
|
|
Charge Time
|
Typically 4 hours
|
|
Internal Radio
|
|
|
Frequency Range
|
410 – 470 MHz
|
|
Protocol
|
CHC, Transparent, TT450 |
|
Emitting Power
|
0.5 W / 2 W
|
|
Operating Range
|
5 km typically
|
b. Controller Software¡úDevice¡úDevice Setting, turn off the ¡°enable voice¡±, and click ¡°OK¡±.
A:The difference between the rover station and the base station is that the accessories are different, the function and hardware configuration are the same. You can use the controller to choose the working mode of the device and set it as the base station or rover station.
A:CORS is called a continuous operating reference station system. It can be understood as a bas e station that is erected at a fixed known point and works continuously for 24 hours, and sends its own data to a specific serverthrough the network. The use of CORS operation eliminates the need for a base station, and CORS is equivalent to a base station in a normalnetwork operation.
