Automatic Calculation 0.5mgon LCD Optical Theodolite

South DT02 Theodolite Electronic Digital Theodolite High Precision Survery instrument

Quick Overview

1. The DT-02 electronic theodolite adopts incremental digital angle measurement system.
2. The resolution of horizontal angle reading and vertical angle reading is 1 ¡° (0.2 mgon).
3. The angle precision is 2¡± (0.5 mgon)
4. The microcomputer techniques adopted in the instrument competes automatic calculation, storage and display.
5. The instrument can display the readings of horizontal angle and vertical angle simultaneously.
6. The DT-02 electronic theodolite adopts incremental digital angle measurement system.
7. The resolution of horizontal angle reading and vertical angle reading is 1 ¡° (0.2 mgon).
8. The angle precision is 2¡± (0.5 mgon)
9. The microcomputer techniques adopted in the instrument competes automatic calculation, storage and display.
10. The instrument can display the readings of horizontal angle and vertical angle simultaneously.

Telescope

• Length> 155 mm
• Object Aperture45 mm
• Magnification30 x
• Image
• Erect Field of View1¡ã 30′
• Resolving Power2.5″
• Minimum Focus1.3m
• Stadia Ratio100
• Stadia Constant0
• Electronic Angle Measurement
• Minimum Reading1″ / 5″ / 10″
• Accuracy (according to DIN18723)2″
• Diameter of Circle71
• Illuminator LCD Yes
• Reticle Plate Yes
• Communication
• EDM Interface No
• Data Export Interface Yes
• Tilt Compensation
• Electric Incline Sensor Vertical Angle Compensation
• Arrange¡À 3′
• Minimum Reading1″
• Optical Plummet
• Magnification3 x
• Field of View5¡ã
• Focusing Range0.5 – ¡Þ
• Level Accuracy
• Plate Level30″ / 2mm
• Circular Level8′ / 2mm
• Power
• Working Time Chargeable Battery 25 hours
• Dimension
• Height of Instrument179.5 mm
• Dimensions (D x H x W)144 x 175 x 324 mm
• Weight (with Battery)4.8 kg
